Reverse Engineering Projects in Orange County
Enhance your CAD file creation by harnessing precise data through 3D laser scanning. We confidently address any engineering challenge.
Free Estimates for Any Size Project
Fully Functional 3D Models
The process of reverse engineering empowers the ability to reconstruct any project into a 3D model; usually in CAD file format. This type of service is ideal for creating files when they are need for manufacturing or cataloging for future work.Â
Utilizing 3D scanning services for reverse engineering purposes, allows for the creation of precise data points like ID, OD, and other dimensions. This allows your data to be digitized with accuracy to the thousandth of a millimeter, creating functional CAD models that can be modified, cycled, and built into assemblies.Â
What is Reverse Engineering?
The reverse engineering Orange County process is the deconstruction of a project in order to decipher its features and dimensions. Most data is then drawn into a CAD file, in other words a 3D model, to then further detail into 2D drawings, especially in manufacturing applications.Â
When you need to improve an existing project design, hiring a team that specializes in reverse engineering Orange County allows you to have as insufficient design documentation for internal designs, or needs CAD data for current production methods, the demand for CAD data arises.
Industries We Serve
- Aerospace
- Advertising
- Agriculture
- AR Digital Assets
- Automotive
- Consumer Products
- Ecommerace
- Legacy Cataloging
- Manufacturing
- Medical Devices
- Motorsports
- Museum and Heritage Preservation
Benefits Reverse Engineering Orange County Services
Universal Files
Offering precise export options, including STEP, IGES, and XT formats, to support manufacturing and modifications.
Ultra-precise Data
Deliver high-resolution data with precise dimensions and volumetric accuracy, accurately representing data like ID, OD.
Part Cataloging
Create accurate digital models of outdated components for easy storage and future use. Enhances ability for quick access and reproduction.
Inventory Management
Maintain an organized database of components with precise specifications, reducing confusion and duplication.
What Clients Say About Our Services
CAD File Creation and More
Creating high-quality 3D models necessitates having all the essential components in place.
In this regard, reverse engineering services play a crucial role by extracting vital elements from scanned data.
The resulting reverse-engineered files are exported in universally compatible formats such as STEP, IGES, and XT.
Please examine the sample folder below to ensure the availability of the files you need.
Why Choose Tangent Solutions
At Tangent Solutions, we offer high-quality 3D laser scanning, product development, and reverse engineer services designed to meet the specific needs of your project.
With deep expertise in product development, reverse engineering, and complex engineering solutions, we deliver tailored services to address even the most unique challenges. Trust us to transform your vision into reality with exceptional precision and support.
Fast turn-around
Same Day Service
Expert Technicans
Universal File Delivery
In-House Teams
3D Scanning Services
for Reverse Engineering, CAD Design, and More.
We offer an extensive array of engineering services, including 3D laser scanning, CAD design, product development, and rapid prototyping.
With our mobile service, our company provides the added convenience of one-day scheduling for our clients.
- 17845 Sky Park Circle Suite E Irvine CA 92614
- Monday - Friday 9am - 5pm
Join a Portfolio of Clients
Previous Reverse Engineering Projects
Tire 3D Scan 37" Tire Rendering
Dirt Bike Rendering
Motor Rendering
Bod Pod Rendering
UTV Rendering
Jeep Rendering
Schedule a Reverse Engineering Meeting
F.A.Q
Our reverse engineering services are $115 per hour. This will create 3D CAD files in STEP, XT, or IGES file formats.Â
Reverse engineering services is performed by drawing a 3D model with 3D scan data as a reference. 3D scan data is ultra-precise and represents detail and dimension to the thousandth of a millimeter.Â
Reverse engineering services creates a CAD file. The most common file formats we can deliver include STEP, IGES, and XT. We can export in many other formats.Â
Yes. Basic post processing during 3D scanning services provides a mesh file in STL file format. You or your engineering must be experienced in redrawing scan data from a mesh file. Common softwares that can complete the reverse engineering process are Geomagic Design X or Fusion 360.
Our office location is in Irvine, California. We work with clients both domestic and international as most work work can be performed remotely.Â
Mobile 3D scanning services, data analysis, product development consulting, CAD design services, and reverse engineering.Â
